Cells Per Unit: 6
Voltage Per Unit 12
Capacity: 120Ah@20hr-rate to 1.75V per cell @25℃
Weight: Approx. 33.5 Kg (Tolerance±3%)
Internal Resistance : Approx. 4.5 mΩ
Terminal : F5(M8)/F12(M8)
Max. Discharge Current: 1200A (5 sec)
Design Life: 12 years (floating charge)
Maximum Charging Current: 36.0 A
Reference Capacity:
C3 89.1AH
C5 100.5AH
C10 114.0AH
C20 120.0AH
Float Charging Voltage: 13.6 V~13.8 V @ 25℃
Temperature Compensation: -3mV/℃/Cell
Cycle Use Voltage: 14.6 V~14.8 V @ 25℃
Temperature Compensation: -4mV/℃/Cell
Operating Temperature Range:
Discharge: -20℃~60℃
Charge: 0℃~50℃
Storage: -20℃~60℃
Normal Operating Temperature Range: 25℃±5℃
Self Discharge: Valve Regulated Lead Acid (VRLA) batteries can be stored for up to 6 months at 25℃ and then recharging is recommended. Monthly Self-discharge ratio is less than 3% at 25℃.Please charged batteries before using.
Container Material: A.B.S. UL94-HB, UL94-V0 Optional.
