Electrical Data
Nominal Voltage (V): 230 - 400
Operating Voltage (%): -15 to +15
Nominal Frequency (Hz): 50 - 60
Maximum Current (A): 3 x 63
Grid Type: 3PN
Power Line Cross Section (mm²): 1 - 16
Neutral Line Cross Section (mm²): 1 - 16
CT's & Comms Line Cross Section (mm²): 0.05 - 4
Self Consumption (W): 1.5
Starting current (mA): 40
Accuracy class: 1
Active energy accuracy: Class B (EN50470)
Reactive energy accuracy: Class 2 (EN/IEC 62053-23)
Short-time overcurrent: 30 x Imax / 0.5 s
Installation & Build
Mounting: Indoors (DIN rail)
Housing: 4 modules DIN 43880
Degree of protection: IP 51 (front frame), IP 20 (terminals)
Ambient temperature range (°C): -25 to +55
Communication & Display
Interface to inverter: Modbus RTU (RS485)
Display: 8-digit LCD
Additional Details
Application: Residential and Light Commercial Solar, Off Grid Solar
Width: 71.2mm
Height: 89mm
Depth: 65.6mm
Weight: 260g
