Electrical Data
Nominal Voltage (V): 120 - 600
Operating Voltage (%): -15 to +15
Nominal Frequency (Hz): 45 - 65
Maximum Current (A): 3 x 6000
Grid Type: 1PN, 2P, 2PN, 3P, 3PN
Power Line Cross Section (mm²): Up to 2.5
Neutral Line Cross Section (mm²): Up to 2.5
CT's & Comms Line Cross Section (mm²): Up to 2.5
Self Consumption (W): 1.75
Starting current (mA): 40
Accuracy class: 0.5
Active energy accuracy: ANSI C12.20 class 0.5 and ANSI C12.1 accuracy
Installation & Build
Mounting: Indoor (wall-mounted); Outdoor (if installed inside an enclosure rated NEMA 3R or 4 / IP66)
Degree of protection: IP 40
Ambient temperature range (°C): -40 to +80
Communication & Interface
Interface to inverter: Modbus RTU (RS485)
Current Transformers: Primary 1 – 6000 A / secondary: use only CTs with voltage output 333 mV
Additional Details
Original Brand: Fronius 43,0001,3591
Description: Fronius Smart Meter WR 100-600 43,0001,3591
Application: Residential and Light Commercial Solar, Off Grid Solar
Width: 85.1mm
Height: 153mm
Depth: 38mm
Weight: 233g
