Fronius Symo GEN24 4.0 Plus SC

FroniusSKU: Symo GEN24 4.0 Plus SC

Price:
$4,449.95
Stock:
Low stock

Description

Fronius Symo GEN 24 4.0 Plus SC Three Phase 4kW Hybrid Inverter with Dual MPPT and WiFi 4,210,191,002

The Fronius Symo GEN24 Plus is a three-phase hybrid solar inverter designed for residential PV and battery storage systems, with flexible backup power options.

It features PV Point for basic backup and supports full backup when connected to a battery and external changeover components. Full backup enables supply to three-phase loads, including high-demand appliances such as heat pumps.

With Multi Flow Technology, the inverter can manage parallel energy flows between PV, battery and loads—even during backup operation—supporting efficient energy use and greater energy independence.

Note: Full backup is not available for 3.0–5.0 models.

Discover the key features for installers and their customers:
  • Intelligent energy management
  • Active cooling technology for a longer service life
  • Flexible and fast installation
  • Easy integration and management of Fronius or third-party components thanks to open interfaces.
  • Dual MPPT
  • IP66 Rated
  • WiFi connection



Pairs perfectly with a Fronius Reserva Battery

The Fronius Reserva is a modular, high-voltage DC solar battery system designed to seamlessly integrate with Fronius GEN24 Plus and Verto Hybrid inverters for backup power and increased energy independence. A slim design, and scalability up to 63 kWh by stacking towers, with a 10-year performance warranty and European data security.



With the PV Point and Full Backup*

The Fronius GEN24 Plus offers two backup power options: a power supply for loads of up to 3 kW via a single socket and a backup power supply for the entire home, including large, three-phase loads such as heat pumps.



Versatility as standard

More functions. More control. More coverage. The Fronius GEN24 Plus continuously saves time and money thanks to their energy management functions.
The device design enables quick and flexible installation, while our software achieves optimal yields – even in shady conditions. At the same time, the integrated active cooling extends the service life and protects your investment.


Built-in freedom

Developed with an open interface so that the integration and control of components from Fronius or third-party providers is particularly straightforward. An integrated and intelligent load management system efficiently uses surplus PV power by prioritising consumers such as heat pumps, pool pumps or wallboxes and controlling them as needed.


Easy monitoring

Everything under control: With our monitoring tool, you can always keep an eye on your PV system and keep your energy revolution on track. And if ever anything isn't quite right, Solar.web automatically notifies the responsible installer.


Sustainability focused

Fronius products and solutions are “Made in Europe” and are consistently developed and implemented with sustainability in mind.

100% recycled aluminium for the heat sinks in all Fronius GEN24 Plus inverters.
100% renewable energy is used for production.
Maximum reparability on-site thanks to easy-to-replace individual components.


This Inverter is available as a PV model: Symo GEN24 4.0 SC

1. Input Data

Range: Symo GEN24 Plus

Single or three phase: Three phase

Number of MPP trackers: 2

DC input voltage range: 80 - 1000V (Udc min - Udc max)

Rated input voltage: 610V (Udc,r)

Feed-in start-up input voltage: 80V (Udc start)

Usable MPP voltage range: 80 - 800V

MPP voltage range (at rated power): 170 - 800V (Umpp min - Umpp max)

2. Output Data

AC rated power: 4000W (Pac,r)

Max. output power: 4000VA (Pac max)

Max. grid power demand: 10VA

Max. AC output current: 8A

3. Output Data PV Point

Max continuous output power: 3000VA

Nom. output current: 13A (Iac max)

Grid connection: 1~NPE 220 V / 230 V

Frequency: 50 Hz / 60 Hz

Max. switchover time PV-Point: 15s

Frequency in backup power mode: 53 Hz

4. General Data

Degree of protection: IP66

Night-time consumption: <10 W

Cooling: Regulated air cooling

Installation: Indoor and outdoor installation

Ambient temperature range: -25°C to +60°C

Permitted humidity: 0 - 100%

Max. altitude: 4000m

Max. efficiency (PV - grid): 98.2%

Additional Details

Description: Fronius Symo GEN 24 4.0 Plus SC Three Phase 4kW Hybrid Inverter with Dual MPPT and WiFi 4,210,191,002

Application: Residential and Light Commercial Solar, Off Grid Solar

Chemistry: Lithium Iron Phosphate (LiFePO4)

Voltage: 80 - 1000V

Termination: M8

Size: 4kW

Width: 474mm

Height: 530mm

Depth: 165mm

Weight: 15.6kg

Technical Documents

Data Sheet.pdf

Operating Instrucitons.pdf
