Fronius Wattpilot Flex Home 22 C6

FroniusSKU: Wattpilot Flex Home 22 C6

Price:
$2,339.95
Stock:
Low stock

Description

Fronius Wattpilot Flex Home 22 C6 1-phase/3-phase electric car charger 4,240,187

The Fronius Wattpilot Flex is a smart EV charger designed to optimise charging using solar power from your PV system.

With intelligent charging modes, it prioritises solar surplus charging and can switch to grid power when needed to ensure your vehicle is ready for the next drive. Ideal for solar EV charging setups, it helps maximise self-consumption and reduce charging costs.

Note: Additional components are required for PV surplus charging.

Your energy, your e-mobility

The PV-optimised wallbox dynamically adapts the charging process to the available solar power. This means that the surplus PV power generated is always used optimally to charge your electric car efficiently and cost-effectively.

There are two intelligent charging modes to choose from: Eco Mode uses your solar power first, while Next Trip Mode ensures that exactly the right amount of energy is charged at a specific time for your next journey at the lowest possible cost. If you have a PV system, the Fronius Wattpilot Flex helps you save on charging and also increase your self-consumption.

Efficiency meets elegance

The Fronius Wattpilot Flex can automatically switch between 1-phase and 3-phase charging. This enables charging with a low starting power (1-phase with 1.38 kWh) when there is a PV surplus. When there is a higher PV surplus, it makes sense to switch to 3-phase operation, as 1-phase charging is limited. In this way, the full potential of the solar energy is utilised.

The modern, elegant design encloses its outstanding functionality.

Intuitive user interface, touch buttons and clear menu navigation

The Fronius Wattpilot Flex offers a user-friendly interface with intuitive touch buttons and clear menu navigation. Integrated WLAN and LAN interfaces allow easy integration into your home network.

The Solar.wattpilot app allows you to conveniently control and monitor the wallbox via smartphone or tablet - anytime, anywhere. Plus, with RFID* technology, you can manage different user profiles and always have full control over all charging processes.

1. Input Data

Range: Wattpilot Flex Home 22 C6

Single or three phase: Automatically switches between 1-phase and 3-phase

Maximum charging power: 1-phase: 7.36kW; 3-phase: 22kW

Grid supply types: TT / TN / IT

Grid connection: 5-pole screw terminal

Nominal voltage: 1-phase: 230/240V; 3-phase: 400/415V

Rated current (configurable): 6–32A (1-phase or 3-phase)

Grid frequency: 50Hz

Charging cable: 6m cable with Type 2 plug

2. General Data

PV optimisation: Dynamic PV surplus charging from 1.38 - 22kW (at 230V / 400V) with automatic 1-/3-phase switching

Energy meter: Standard meter (non-calibrated)

Standby consumption: 3.5 - 6.8W (depending on settings)

Installation: Indoor and outdoor installation

Protection class: IP66

Ambient temperature: –25°C to +45°C

Air humidity: 5 - 95% (non-condensing)

Additional Details

Description: Fronius Wattpilot Flex Home 22 C6 1-phase/3-phase electric car charger 4,240,187

Application: Electric Vehicles, E-mobility

Width: 195mm

Height: 325mm

Depth: 105mm

Weight: 5.4kg

Technical Documents

Fronius Wattpilot Flex.pdf

Fronuis Verto Plus.pdf
